TP-LINK
 RE205
AC750
 Wi-Fi Range
Extender

MESH-WI FI EXTENDER-TP-LINK-AC750-RE205

LE 1,550.00
SKU: 52923
Availability : In stock Pre order Out of stock
Description

TP-LINK RE205 AC750 Wi-Fi Range Extender - Technical Specifications

Brand TP-LINK
Model RE205
Hardware Features
Plug Type EU
Ports 1 x 10/100Mbps Ethernet Port (RJ45)
Button WPS Button, RESET Button
Input Power 100-240V~50/60Hz
Power Consumption 7.2W
Dimensions (W x D x H) 77.8 x 40 x 80 mm
Antenna 2 External Antennas
Wireless Features
Wireless Standards IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency 2.4GHz and 5GHz
Signal Rate 300Mbps at 2.4GHz, 433Mbps at 5GHz
Working Modes Range Extender/Access Point
Reception Sensitivity

5GHz:

11a 6Mbps: -94dBm

11a 54Mbps: -77dBm

11ac HT20: -69dBm

11ac HT40: -66dBm

11ac HT80: -63dBm

2.4GHz:

11g 54Mbps: -79dBm

11n HT20: -77dBm

11n HT40: -74dBm

Wireless Functions

Enable/Disable Wireless Radio

DFS (the latest firmware and hardware version is required)

Access Control

LED Control

Power Schedule

Wi-Fi Coverage

Wireless Security WEP, WPA/WPA2-PSK encryptions, Enable/Disable SSID Broadcast
Transmission Power 2.4 G≤20dBm, 5 G≤20dBm
Others
Certification CE, RoHS
Package Contents

AC750 Wi-Fi Range Extender RE205

Quick Installation Guide

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10,

MACOS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0,

Chrome 20.0, Safari 4.0, or other Java-enabled browser

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
